High Effciency Industrial Portable Outdoor Cabinet Air Conditioner
for Control Cabinet
Product Characteristic
This Type outdoor Air Conditioner Cooling Solution can be widely
used in the area for climate control, such as wireless
communication cabinet, battery cabinet,industry control cabinet
etc. the outdoor cabinet air conditioners are designed to cool your
electronic and electrical controls, instruments, computer
terminals, printers, telecommunications equipment, surveillance
devices, cameras, laser and optical equipment and many other
electronics in variety of environments. Our electronic cabinet
cooling systems are designed for use with a wide range of
enclosures and transit cases. Models are available for both indoor
and outdoor use in AC and DC power configurations. Coolers feature
corrosion-resistant stainless steel construction.
Product Advantage
● 220VAC power input
● 300-3000W cooling capacity (L35L35)
● Door mounted – easy integration in outdoor cabinets
● Optional configured with heater
● Wide working temperature range: -15ºC to +55 ºC
● Energy saving
● Lifetime >10 years – minimum maintenance
● Environmental friendly – R134a and RoHS compliant
● Resistant to corrosive environments – IP55 and Salt fog tested
● RS485 for remote control
● Soft start
● Easy installed that one person can finish the work
● Multi-Function alarm output.
● High energy efficiency reach 4.5.
Specifications
| Model | Mounting method | Input voltage | Dimensions (Include flange).MM | Dimensions (Without flange) | Cooling capacity (L35/L35).W | Power consumption (L35/L35).W | IP grade | Noise dB (A) | Certification |
LCA003EA
LCA004EA | Side/ Embedded | AC 220V±15% 50Hz±3 | 352*175*583 | 315*175*546 | 300
400 | 170
200 | 55 | 60 | CE&3C |
LCA005EA
LCA006EA | 352*175*583 | 315*175*546 | 500
600 | 210
260 | 55 | 60 | CE&3C |
LCA008EA
LCA010EA | 482*175*782 | 445*175*745 | 800
1000 | 340
440 | 55 | 65 | CE&3C |
LCA013EA
LCA015EA | 482*175*782 | 445*175*745 | 1300
1500 | 550
650 | 55 | 65 | CE&3C |
LCA020EA
LCA023EA | 482*200*782 | 445*200*745 | 2000
2300 | 870
900 | 55 | 65 | CE&3C |
LCA025EA
LCA030EA | 536*225*1201 | 485*225*1150 | 2500
3000 | 1090
1300 | 55 | 65 | CE&3C |
Product details
- Remote measuring, remote communication, remote control, which can
realize multiple automatic protection and comprehensive
self-testing function.
- Strict process control and famous brand components to ensure high
quality and reliability of this product
- Fit for harsh condition (T3),R134 a refrigerant
- Multiple self-protection design, RS485 communication port
(MODBUS-RTU protocol)
- LED display, all the setting can charge at the field.
- The heating function is optional
- Dry contact alarm output, NO/NC optional
- Anti-theft design, without the protection cover.
Installation Diagram
Application
In order to comply with the development requirements of national
energy conservation, environmental protection and low carbon
economy, we have continuously transformed and upgraded, and
invested heavily in cabinet air conditioners and industrial air
conditioners, and successfully developed more efficient and
energy-saving air conditioning units.
The products are widely used in
- telecommunications,
- electric power
- industrial automation
- rail transit
- automobiles
- CNC machine tools and other fields.
- Indoor and Outdoor Battery Cabinet
- Wireless Indoor and Outdoor Cabinet
- Indoor and Outdoor Hybrid Base station
FAQ
1. Q: How about the air cooler material?
A: It makes by 100% new plastic, pure copper for motor.
2. Q: What voltages you can do, could you make special voltages?
A: we can make DC48 and all AC voltage products for you.
3. Q: I want to use our own brand, is it OK?
A: It is possible, we supply the OEM products too.
4. Q: How about the warranty?
A: All the unit warranty is one year.
