500W AC220V Outdoor Cabinet Air Conditioner with Intelligent
Controller
Product Characteristic
The 500W outdoor cabinet air conditioner is a full automation
temperature control product. It uses intelligent controller to
control the whole system of the air conditioner. According to the
variation of environment temperature, the intelligent controller
can automatically detect, operate and record the whole system’s
operating time, power consumption, event and historical data. It
can store 100 event records and 1280 historical data records, and
can enquire 256 days’ daily record information.
1.Specifications
Technical Parameters
| Environmental Performance | working environmental temperature | -20°C ~ 55°C |
| storage temperature | -40°C ~ 70°C |
| working humidity | ≤95% |
| Thermal Performance | rated cooling capacity | 500W(L35 L35) |
| rated heating capacity | 300W/500W (optional) |
Electrical Performance | rated input current | 2.35A(L35 L35) |
| rated input power | 517W(L35 L35) |
| rated input voltage | AC220V~240V/50HZ |
| Noise | ≤65dB |
| Reliability | MTBF | 70000h |
| Refrigerant | R410A |
Product Advantage
(1) Strong adaptability
(2) High intelligence
(3) High precision
(4) High reliability
(5) Low noise
(6) Low energy consumption
(7) With 4 way switching value detection
(8) With 1 way room air conditioner control
Voltage input range: 220VAC±15% 50Hz
With dry contact alarm output
Specification sheet
| Place of Origin: Shenzhen, China (Mainland) | Rated Cooling Capacity : 500W |
| Brand Name: CYNRIN | Rated Heating Capacity:500W(optional) |
| Model: CCA003EA | Dimension: H×W×D 352*175*583mm |
| Product Name: Outdoor Cabinet Air Conditioner | Input Voltage: AC220V/50Hz |
| Certification: ISO9001, CE, 3C, | Rated Input Current: 2.2A |
| Cover Material: galvanized steel | Rated Input Power: 484W |
| Color: grey | Working Temperature: -20°C ~ +55°C |
| Protection Level: IP55 | Noise: ≤64dB |
| Installation Mode: door mounted | Refrigerant: R410a |
| Support OEM | Cooling Method: compressor, active cooling |
Product details
Dimension Diagram: H×W×D: 352*175*583mm
- Remote measuring, remote communication, remote control, which can
realize multiple automatic protection and comprehensive
self-testing function.
- Strict process control and famous brand components to ensure high
quality and reliability of this product
- Fit for harsh condition (T3),R134 a refrigerant
- Multiple self-protection design, RS485 communication port
(MODBUS-RTU protocol)
- LED display, all the setting can charge at the field.
- The heating function is optional
- Dry contact alarm output, NO/NC optional
- Anti-theft design, without the protection cover.
Installation Diagram
Application
The products are widely used in
- telecommunications,
- electric power
- industrial automation
- rail transit
- automobiles
- CNC machine tools and other fields.
- Indoor and Outdoor Battery Cabinet
- Wireless Indoor and Outdoor Cabinet
- Indoor and Outdoor Hybrid Base station
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
| Price: | negotiation |
| Payment Terms: | T/T, L/C, etc |
| Supply Ability: | 1,0000 sets per month |
| Delivery Time: | 10-15 working days |
| Packaging Details: | carton + wooden case + pallet
|
FAQ
1. Q: How about the air cooler material?
A: It makes by 100% new plastic, pure copper for motor.
2. Q: What voltages you can do, could you make special voltages?
A: we can make DC48 and all AC voltage products for you.
3. Q: I want to use our own brand, is it OK?
A: It is possible, we supply the OEM products too.
4. Q: How about the warranty?
A: All the unit warranty is one year.
